3DCeram C3601 ULTIMATE
Mass‑production ceramic 3D printer with one of the largest platforms on the market for technical ceramics. Easy scale up from C101 EASY Printer.
- 600×600×300 mm build for one‑piece large parts
- Serial printing capable with reduced unit cost
- CERIA by AI ready.
Large‑format top‑down laser stereolithography for big parts or series with optimized recycling time.
Technical Specifications
600 × 600 × 300 mm
2100 x 1800 x 2500 mm; approx. 4000kg
Top‑down SLA; few or no supports required
UV Wavelength
405 nm
Laser Spot Diameter
~ 60 µm
Popular Applications
%20Printed%20Model_2%20J5%20Digital%20Anatomy%20Printer.avif)
%20tooling.avif)
Model Materials
Supports a wide range of technical ceramics.
Zirconia 3Y
High hardness, chemical inertness, excellent mechanical properties
C101 EASY, C900 FLEX, C1000 FLEXMATIC
Dental crowns and bridges, orthopedic implants, wear-resistant components, electronics
- Used in high-stress environments
- Ideal for precision components requiring both aesthetics and strength
- Typically sintered at ~1450–1550°C for full density
Zirconia 8Y
Excellent ionic and oxygen-ion conductivity, thermal insulation.
C101 EASY, C900 FLEX, C1000 FLEXMATIC
Fuel cells, energy systems
- Used in solid oxide fuel cells (SOFCs)
- Functions efficiently under extreme heat
Hydroxyapatite (HAp)
High biocompatibility, osteoconductive
C101 EASY, C900 FLEX, C1000 FLEXMATIC
Biomedical implants, bone scaffolds
- Similar chemical composition to natural bone
- Promotes bone growth
- Used in custom orthopaedic and dental implants
Silicore
Porous structure, high mechanical strength, stable at high temperatures
C101 EASY, C900 FLEX, C1000 FLEXMATIC
Foundry cores
- Excellent leachability
- Custom-made for high-temp core-making in complex castings
- Compatible with all alloys except cobalt
Silicon Nitride (Si₃N₄)
Known for its excellent thermal shock resistance, high hardness, and superior wear and corrosion resistance.
C101 EASY, C900 FLEX, C1000 FLEXMATIC
Aerospace, automotive components, medical implants, energy systems
- Withstands high temperatures (~1800°C)
- Corrosion-resistant and frequently used in engine and turbine parts
Aluminium Nitride (AlN)
High thermal conductivity, excellent electrical insulation, good mechanical strength
C101 EASY, C900 FLEX
Electronics industry – substrates, heat sinks, and circuit components
- Commonly used in power electronics, LEDs, and microelectronic packaging.
- Maintains stability in high-temperature and high-voltage environments
